CW Series

Home » Products » Casters » Light Medium Duty Series » CW Series

Filter & Sort

CWTP50GY4711YZ

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" w/ bearing cap single precision ball bearing

CWTP50GY9006TY

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9006TZ

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9006YY

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9006YZ

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9011TY

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9011TZ

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9011YY

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8"x1/2" bushing

CWTP50GY9011YZ

Series: Short-offset swivel casters
Wheel Color: gray tread/zinc centered hub
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Thermo-Pro" thermoplastic rubber/polyolefin wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8"x1/2" bushing

CWUN35GLA306TY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 10" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN35GLA306YY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 10" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN35GLA306YZ

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 10" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA306TY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA306YY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA306YZ

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA311TY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA311YY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN40GLA311YZ

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA306TY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA306YY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA306YZ

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA311TY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA311YY

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUN50GLA311YZ

Series: Short-offset swivel casters
Wheel Color: black, Shore 70~75A
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Nickel plated disc wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" i.d. integrated engineering bearing

CWUT30GI8206TY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT30GI8206YY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT30GI8206YZ

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT40GI8206TY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT40GI8206YY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT40GI8206YZ

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT40GI8211TY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUT40GI8211YY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUT40GI8211YZ

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUT50GI8206TY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT50GI8206YY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT50GI8206YZ

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWUT50GI8211TY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUT50GI8211YY

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUT50GI8211YZ

Series: Short-offset swivel casters
Wheel Color: gray/gray
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "Utility Heat" wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWUX30GO6206TY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX30GO6206YY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX30GO6206YZ

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6206TY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6206YY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6206YZ

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6211TY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6211YY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX40GO6211YZ

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6206TY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6206YY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6206YZ

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6211TY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6211YY

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWUX50GO6211YZ

Series: Short-offset swivel casters
Wheel Color: orange
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: "UltraFlex" donut tread ergonomic polyurethane/aluminum wheel
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 6202 w/ 3/8" i.d. top hats

CWVG30GT8206TY

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWVG30GT8206YY

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWVG30GT8206YZ

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWVG30HT0306TY

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/2" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/4"x1-3/16"x1-3/8" roller

CWVG30HT0306TZ

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/2" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/4"x1-3/16"x1-3/8" roller

CWVG30HT0306YY

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/2" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/4"x1-3/16"x1-3/8" roller

CWVG30HT0306YZ

Series: Short-offset swivel casters
Wheel Color: v-groove 7/8"
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/2" tread w.
Wheel Type: Cast iron v-groove wheel
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/4"x1-3/16"x1-3/8" roller

CWZZ30GZ8206YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 3" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWZZ35GZ8206YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 10" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWZZ40GZ8206YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWZZ40GZ8211YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 4" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

CWZZ50GZ8206YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 2-3/8"x3-5/8" (bolt 1-3/4"x2-7/8" to 3") plate
Bearing: 3/8" plain bore

CWZZ50GZ8211YY

Series: Short-offset swivel casters
Wheel Color: black-crowned
Wheel Overall Diameter: 5" o.d.
Wheel Total Width: 1-1/4" tread w.
Wheel Type: Yoke only
Fastener: 3-1/8"x4-1/8" (bolt 1-3/4"x2-15/16" to 2-3/8"x3-3/8") plate
Bearing: 3/8" plain bore

« 1 2 … 43 44 45 46 »

We're always around!™

Our expert Account Managers are ready to roll out solutions for a purchasing experience that exceeds all expectations.
At Durable Superior Casters, the products are durable, the service is superior, and the shipping is fast. What can we build for you?
